Allied Automated Control Panel

Automated

Control Systems

Allied Automated Control systems. Engineered and manufactured in-house in Allied's CSA Ul certified panel shop.

Intuitive, User Friendly Controls
Plug & Play, Minimal Setup & Tear down
Powerful & Reliable Drives
CSA & UL Certified Panel Shop
Engineered & Manufactured In-House
Engineering & Manufacturing

All Allied automated control systems are complete full package solutions, fit to your specific processing requirements. From the design to procurement, fabrication, quality control, installation and commissioning. All Allied controls are fabricated using robust quality CSA/UL certified parts and materials while also offering a variety of industry leading technology with customizable options to fit your requirements

Allied Control Panel Open

  • PLC Control Panels

  • DCS Marshalling Panels

  • Compressor Control Systems

  • SCADA Panels

  • Relay Panels

  • Control/Operator Interface Consoles

  • Instrumentation Panels

  • VFD Control Panels

  • BMS Panels

  • Light Contactor Panels

  • Process Panels

  • Remote I/O Panels

  • HVAC Control Panels

  • Radio/Communication Panels

  • Termination Junction Boxes

  • Networking Enclosures

  • Insulated Battery Enclosures

  • Protection Panels

  • Combinations Starters

  • Electrical Skids & Buildings

  • Heat Trace Contactor Panels

  • Solar Pump Packaging

  • Booster Pump Panels

  • RTU Control Panels

  • Oilwell Controls

  • Waste Water Control Panels

System Types
Intuitive & User Friendly

  • Intuitive operator HMI touch screen offers superior live data visualization and trending features

  • Bright wide 15" class 1 div 2 operator displays, subzero rated

  • Easy to navigate software offers quick parameterization of equipment

  • Easy to integrate with existing DCS control system

  • Plug and play with minimal wiring necessary

  • LED lit interior panel

HMI touch screen on an Allied Manufactured Control Panel
Power inlet and plugs on allied control panel
Secure Accessibility & Technical Support

  • Secure remote communications, you can access anywhere in the world with either tablet or laptop

  • Password protected

  • Optional secure encrypted access through satellite, cell/sim card or wifi keeps you in touch with your remote support engineering team 24-7

  • Our in house engineering support team provides PLC programming services and a variety of SCADA solutions for site wide control applications, production reporting and remote alarming to site personnel

  • Commissioning and on-sight support available

HMI siplay screen on an Allied centrifuge technologies control panel
Ultimate Processing Control

  • Fully automatic operation using state of the art PID controls

  • Programmable speed and differential controls using the latest in VFD technology, offers flexibility and optimal equipment performance

  • Software customized to suit your specific application requirements

  • Unlimited horsepower/Voltage combinations

  • SCADA systems available featuring VTSCada/ignition and factory talk plant PAX

Drives inside an Allied Control panel
Integrated Technology

Allied incorporates the top industry leading technology into its panels. We guarantee our systems are built using only CSA/Ul marked components. Allied is a non vendor specific panel facility and will accommodate any specific​ client requests when it comes to brand loyalty. Our facility stocks all panel components, VFD's and screens. No lead times, no waiting. Parts immediately available.

Retrofitting & Upgrading

Looking to upgrade existing and out of date controls? Allied can integrate new technology into existing infrastructure. Upgrade specific technology like VFD's HMI screens and more, along with programming changes and updates.

breakers and wiring inside an Allied Manufactured Control Panel
Certified Panel Manufacturer

  • Each system is factory tuned and carefully FAT tested in our CSA/UL certified panel facility​

  • Certified by Canadian Standards Association to manufacture industrial control panels to CSA C22.1 and UL 508A. Panels are certified for use in Canada and the United States

CSA Certified panel shop
UL Certified Panel Shop
Enclosures & Ratings

  • Class 1 Div 1 or Div 2, Groups B, C and D

  • Intrinsic, Non-incendive, EXP circuits

  • Special instrument and control assemblies containing hazardous locations components, certified to Canadian standards (or specific location standards)

  • Special instrument and assemblies for process and control applications

  • Enclosure types NEMA 1, 2, 3, 4 and 4X

  • Explosion proof and intrinsically safe

  • Purged and air conditioned units available

Allied Centrifuge Technologies Manufactured Control Panel
